This text/workbook with
CD-ROM presents basic
elements of blueprint reading and provides blueprint reading experience in
residential construction.
The entire process of reading residential blueprints, from
working drawings and blueprint making techniques to reading and
interpreting finished plans, is covered in detail.
Two sets of residential blueprints are included with the text.
Content is applicable to a variety of building trades including
carpentry, electrical, plumbing, and HVAC.
The fifth edition has been updated to include coverage in the areas
of green building technology and construction, residential fire
protection, sustainable energy systems, the latest print production
technology, and expanded building trade roles, materials, and
methods. Chapters conclude with review exercises, extensive
sketching activities, and trade competency tests designed to
challenge learners and reinforce the material presented in the
textbook
The
CD-ROM includes Quick Quizzes™, an Illustrated Glossary,
Stewart Residence - Prints, Stewart Residence - 3D Model, Master
Math™ Problems, Media Clips, and Reference Material.

2 Complete Sets of Prints are included
An Appendix and illustrated Glossary complete this excellent
text.
