Ultra Scale Master Pro
Ultra Scale Master
Pro Digital Takeoff Tool and Blueprint Plan Measuring Tool with Smart Takeoff
Graphic Digitizing Software
(Buy Both and
Save $119.00)
For
Construction Estimators, Contractors or Anyone Who Works with
Blueprints and Plans
- Measure and calculate areas, lengths and volumes for all
types of polygons
- See graphic representation of digitized drawings
- Easily send computed measurements to spreadsheet or
estimating programs.
- Affordable, portable and powerful
- Fast and easy-to-use
- Works as Stand-alone or Computerized Plan Measuring Device
 Take
full advantage of your Ultra Scale Master® Pro digitizing
capabilities by using Smart Takeoff!™-
an optional affordable and
simple-to-use graphic digitizing program. When combined with the
speed and accuracy of the Ultra Scale Master® Pro digitizing tool,
this system is invaluable as part of any construction cost
estimating system.
Smart Takeoff!™
provides graphic representation of
the digitized coordinates for the Ultra Scale Master® Pro, and
verifies quantities while minimizing, or even eliminating, errors of
omission and miscalculation.
Use
Smart Takeoff!™ to
determine quantities of area, perimeter, length, and vertical
surface area for compiling construction cost estimates.
 Smart Takeoff!™
transfers digitized quantities to virtually any Windows® based
program including spreadsheets (spreadsheet program not included),
and also allows you to export the graphic image in DXF format for
use in other programs.
The Ultra Scale Master® Pro can also
operate as a stand alone digital area takeoff tool and blueprint
plan measuring tool, or you can
connect it to your PC to transfer measurements into any estimating
and spreadsheet program that accept text input from a number pad or
keyboard.
The ergonomic design of the Ultra Scale Master
Pro with large targeting
window allows you to accurately measure and compute areas, segment
lengths, perimeters, and volumes for simple or complex polygons,
polylines, irregular shapes, arcs and circles.
72 built-in architectural and engineering
scales allow you to measure blueprints, plans and drawings up to 24" x 36" in
size. Four custom scales allow you to measure out of scale drawings.
Ultra Scale Master Pro Features:
Smart
Takeoff! Software
- USB Plug-and-Play interface
- Works with any scale
- Digitizes areas, perimeters and lengths
- Two- and three-dimensional perspective graphic display of
digitized images
- Transfers digitized quantities into any Windows® program,
including spreadsheets!
- Draws in any color available in the Windows® palette
- Seven fill styles for area objects
- Selectable line weight
- Auto-zooms image so that it always fits the computer’s
display
- Exports graphic image to DXF (Drawing Exchange Format) files
- Measures unknown scales on reduced or enlarged drawings
- Supports both imperial and metric units
Measuring Shapes
- Simple or Complex Polygons
Measure all polygon points and automatically find area, line
lengths, perimeter and volume.
Rooms, walls concrete pads, parking lots, floor coverings, and
small site excavations
- Polylines
Measure two or more points and automatically get segment length,
total length and wall area.
Walls, foundations, piping, electrical, and other linear
measurements
- Irregular Shapes
Measure all points on the curved shape and automatically find
area, perimeter and volume.
Pools, planting beds, curbing, and water proofing
- Arcs
Measuring the starting point, high point and finishing point of
the arc and automatically get area, perimeter, arc length,
volume, and wall area.
Arched windows and doorways
- Circles
Select any three point on the circle and automatically get area,
perimeter, volume, radius and diameter.
Columns and roundabouts
 Ultra Scale Master Pro Operating Modes
- Stand Alone Operation
Measure and display line lengths, areas, perimeters, volume,
wall areas, arc lengths, radius and diameter without the use of
a PC.
- PC Input Mode
Send displayed values to your spreadsheets and estimating
software programs via supplied USB cable (no special USB driver
software needed).
- Digitizer (x,y) Coordinate Entry
Send coordinates to graphic digitizing software like our Smart
Takeoff! program.
Additional
Features
- Ergonometric shaped measuring device and
large targeting window gives you point-to-point measuring
accuracy
- Easy to read LCD display
- 72 built-in scales or create custom
scales for out-of-dimension drawing and plans
- Imperial or Metric Mode
- Change units of measure of any displayed
value at any time
- Easily recall line lengths and computed
measurements for current measured shape
- Enter a stored height and get volume and
wall area calculations
- Operates on 4 –AAA batteries (included)
or from USB Cable when connected to PC
- Automatic Shut-Off saves battery life
Preference
Settings:
- Display Total Measurements or last
segment measured
- Beep sound control
- US/Euro value display
- PC Send Display after data is sent to the
PC
- PC data terminating command settings
allow you to control spreadsheet cell direction
- Set Right Hand or Left Hand Digitizer
mode
- USB Send Delay control for slower
computers
Includes:
- Measuring Device (Puck)
- 4-AAA batteries
- Padded Leatherette Puck Case
- USB Cable
- Reflector Bars
- Quick Setup Sheet
- Quick Reference Guide
- Fully Illustrated User’s Guide
- Hard, Durable Molded Carrying Case
- Smart Takeoff! software
The Ultra Scale Master Pro®/Smart Takeoff! comes
with a Manufacturers 1-Year Limited Warranty.
 Ultra Scale
Master Pro
Specifications:
Smart Takeoff! software requirements:
- Windows® 2000, XP and Vista 32-bit Operating Systems
- One USB port for the Ultra Scale Master® Pro
- 1.6Hz Pentium microprocessor minimum
- 256 MB RAM minimum
- 10 MB available hard drive capacity
- XVGA or higher resolution color graphics display
- CD-Rom Drive
Computer Interface:
USB 1.1 and 2.0 compatible HID Mode via supplied
cable
Bar Specifications:
- Footprint
25.63 x 37.63 x 1.40 inch (651 x 956 x 36 mm)
- Active Measurement Area
24 x 36 inch (610 x 914 mm) (re-configurable)
- Weight
2.31 Lbs (1049 grams)
Puck Specifications:
- Footprint:
3.79" x 7.63" x 1.13" (98.4 x 193.6 x 28.5 mm)
- Weight:
7 oz (200 grams)
- Power Source:
USB power when connected to PC
4 “AAA” batteries when used as stand alone device
- Range:
Up to 36 inches
- Accuracy:
±0.040 inch (± 0.1016 cm)
- Operating Temperature:
41 to 104°F (5 to 40°C)
- Storage Temperature:
14 to 122°F (-20 to 60°C)
Humidity Range:
0 to 95%, non-condensing
Warranty:
1-year manufacturers limited warranty
|
