Choice of Models for High Intensity Measurements up to 999,900 Lux & 99,900 Foot Candles

Glossary of Terms

Specifications - EA30/EA31 (PDF File) Specifications - EA33 (PDF File)

Features:

• Compact and rugged design features large display

• Data hold freezes reading on display

• MIN/MAX readings

• Zero function

• Cosine and color corrected measurements

• Low battery and overrange indication

• Auto power off to save battery life

• Utilizes precision silicon photodiode sensor with 3ft coiled cable for easy storage

• Multiple wide measuring ranges:
  Model EA31 - 20,000Fc in 4 ranges and 20,000Lux in 4 ranges
  Model EA30 - 40,000Fc in 4 ranges and 400,000Lux in 5 ranges
  Model EA33 - 99,990Fc in 5 ranges and 999,900 Lux in 5 ranges

• Complete with built-in stand, remote sensor with protective cover, protective rubber holster, and 6 AAA batteries

• Large display with bargraph

• Peak hold captures short light pulses to 100µSec

• Relative function for zero or difference from reference value

• Large LCD Display with Advanced Illuminance Functions and Features

• Wide measurement range to 99,990Fc (999,900 Lux) with resolution of 0.001Fc and 0.01Lux

• Luminous intensity (candela) calculations

• Store and recall up to 50 measurements, includes relative or real time clock stamp

• Ripple function excludes the effect of stray light from the primary light source measurement

• Timed-Hold, Relative in absolute value or % deviation, and Comparator function with high low alarms
