Graphic Guide to Frame Construction: For Pros by Pros
Practical Framing Details for Builders and Designers of Frame Construction

By Rob Thallon

Practical Framing Details for Builders and Designers

The newly revised and updated edition of this classic reference volume reflects all the latest innovations in residential frame construction.
Ideal for builders, architects, students or anyone interested in building their own home, The Graphic Guide to Frame Construction is a new addition to our popular series of books For Pros By Pros.

Filled with hundreds of meticulous drawings and framing diagrams, this comprehensive visual handbook shows you every precise detail you need to know about framing with wood.

Building on the success of two earlier editions -- which have sold over 230,000 copies -- accomplished architect and teacher Rob Thallon brings you up to date on new framing materials, construction framing methods, and building code revisions.

And because examples are taken from actual job sites -- by a trusted professional -- it's all reliable, field-tested framing information you can put to work immediately.

Here are as few examples of what you'll find:

• Step-by-step details for advanced framing
• How to use modern-engineered and composite framing materials
• Strategies for building in high wind and seismic areas
• Expert advice on foundations, framing floors, framing walls, framing roofs and stairs

Whether you're a builder, architect or homeowner, you'll find this up-to-the-minute resource is the perfect visual aid to help you tackle a wide range of framing projects with confidence.

Also by Rob Thallon:
Graphic Guide to Interior Details
Graphic Guide to Site Construction

Table of Contents:

Introduction

1 FOUNDATIONS

Footings
Foundation Walls
Pier & Grade-Beam Systems
Basement Walls
Retaining Walls
Drainage & Waterproofing
Wall Caps
Slabs
Utilities

2 FLOORS

Beams
Joist Systems
Girder Systems
Subflooring
Porches & Decks
Insulation

3 WALLS

Framing
Lateral Bracing
Sheathing
Shear Walls
Moisture & Air Barriers
Windows
Doors
Flashing
Exterior Finishes
Insulation

4 ROOFS

Framing
Sheathing
Flashing
Roofing
Gutters & Downspouts
Insulation & Ventilation

5 STAIRS

Framing
Treads & Risers
Balustrades
Handrails
Exterior Stairs
Exterior Steps

Legend

List of Abbreviations

Resources

Glossary

Index

Soft-cover, 8-1/2 x 11 in., 240 pages, with color photos and drawings  Published 2009

ISBN 978-1-60085-023-3

Paperback, 243 pages

Graphic Guide to Frame Construction (For Pros By Pros) Qty: 1600850235 $24.95 $19.80 Free Super Saver Shipping Usually ships in 24 hours
